PRESIDENT METAL & ALLOYS

ALUMINUM

ALUMINUM

2XXX SERIES

Copper is the principle alloying element in this group. These alloys require solution heat-treatment to obtain optimum properties. It is used in applications requiring high strength to weight ratio, as well as good fatigue resistance. It is weldable only through friction welding, and has average machinability. Due to its high strength and fatigue resistance, 2024 is widely used in aircraft structures, especially wing and fuselage structures under tension. We stock 2014, 2024 & 2219 grade extrusions.

2014 ALUMINUM EXTRUSIONS

CURRENTLY OFFERING TO THE FOLLOWING SPECIFICATIONS:

  • AMS-4153
  • ASTM-B221

Latest Designation: AMS-QQ-A200/2

Other Specifications: ABS, ASNA, LN, Werkstoff, NTA, DAN, AIR



2014
2014 Others
Weight% Si Fe Cu Mn Mg Cr Zn Ti Each Total
Minimum 0.5 3.9 0.4 0.2
Maximum 1.2 0.7 5 1.2 0.8 0.1 0.25 0.15 0.05 0.15

Remainder Aluminum

2024 ALUMINUM EXTRUSIONS

CURRENTLY OFFERING TO THE FOLLOWING SPECIFICATIONS:

  • AMS-4152, AMS-4164, AMS-4165
  • ASTM-B221

Latest Designation: AMS-QQ-A-200/3

Other Specifications: ABS, ASNA, LN, Werkstoff, NTA, DAN, AIR




2024
2024 Others
Weight% Si Fe Cu Mn Mg Cr Zn Ti Each Total
Minimum 3.8 .3 1.2
Maximum 0.5 0.5 4.9 .9 1.8 0.1 0.25 0.15 0.05 0.15

Remainder Aluminum

2219 ALUMINUM EXTRUSIONS

CURRENTLY OFFERING TO THE FOLLOWING SPECIFICATIONS:

  • AMS-4162, AMS-4163
  • ASTM-B221

Designer Specifications: BMS7-118, DMS-2077

6XXX SERIES

Alloys in this group contain silicon and magnesium in approximate proportions to form magnesium silicide, thus making them heat-treatable. The major alloy in this series is 6061, one of the most versatile in the heat treatable alloys. Though less strong than most of the 2xxx or 7xxx alloys, the magnesium-silicide alloys possess good formability and corrosion resistance, with medium strength. We stock 6061 & 6063 grade extrusions.

6061 ALUMINUM EXTRUSIONS

CURRENTLY OFFERING TO THE FOLLOWING SPECIFICATIONS:

  • AMS-4150, AMS-4160, AMS-4161, AMS-4172, AMS-4173
  • ASTM-B221

Latest Designation: AMS-QQ-A-200/8

Other Specifications: ABS, ASNA, LN, Werkstoff, NTA, DAN, AIR



6061
6061 Others
Weight% Si Fe Cu Mn Mg Cr Zn Ti Each Total
Minimum 0.4 0.15 0.8 0.04
Maximum 0.8 0.7 0.4 0.15 1.2 0.35 0.25 0.15 0.05 0.15

Remainder Aluminum

6063 ALUMINUM EXTRUSIONS

CURRENTLY OFFERING TO THE FOLLOWING SPECIFICATIONS:

  • ASTM-B221

Latest Designation: AMS-QQ-A-200/9

Other Specifications: ABS, ASNA, LN, Werkstoff, NTA, DAN, AIR

6063
6063 Others
Weight% Si Fe Cu Mn Mg Cr Zn Ti Each Total
Minimum 0.2 0.45
Maximum 0.6 0.35 0.1 0.1 0.9 0.1 0.1 0.1 0.05 0.15

Remainder Aluminum


7XXX SERIES


Zinc is the major alloying element in this group, and when coupled with a smaller percentage of magnesium results in heat-treatable alloys of very high strength. Other elements such as copper and chromium are also added in small quantities. The most common member of this group is 7075, which is among the highest strength alloys available and is used in airframe structures and for highly stressed parts. We stock 7050, 7075, 7150 & 7178 grade extrusions.

7050 ALUMINUM EXTRUSIONS

CURRENTLY OFFERING TO THE FOLLOWING SPECIFICATIONS:

  • AMS-4340, AMS-4341, AMS-4342

Latest Designation: DMS-2227

Other Specifications: ABS, ASNA, LN, Werkstoff, NTA, DAN, AIR

7050
7050 Others
Weight% Si Fe Cu Mn Mg Cr Zn Ti Zr Each Total
Minimum 2 1.9 5.7 0.08
Maximum 0.12 0.15 2.6 0.1 2.6 0.04 6.7 0.06 0.15 0.05 0.15

Remainder Aluminum

7075 ALUMINUM EXTRUSIONS

CURRENTLY OFFERING TO THE FOLLOWING SPECIFICATIONS:

  • AMS-4154, AMS-4166, AMS-4167, AMS-4168, AMS-4169
  • ASTM-B221

Latest Designation: AMS-QQ-A-200/11, AMS-QQ-A-200/15

Other Specifications: ABS, ASNA, LN, Werkstoff, NTA, DAN, AIR

7075
7075 Others
Weight% Si Fe Cu Mn Mg Cr Zn Ti Zr Each Total
Minimum 2 1.9 5.7 0.08
Maximum 0.12 0.15 2.6 0.1 2.6 0.04 6.7 0.06 0.15 0.05 0.15

Remainder Aluminum

7150 ALUMINUM EXTRUSIONS

CURRENTLY OFFERING TO THE FOLLOWING SPECIFICATIONS:

  • AMS-4345

Latest Designation: BMS7-257, BMS7-306, DMS-2256

Other Specifications: ABS, ASNA, LN, Werkstoff, NTA, DAN, AIR

7150
7150 Others
Weight% Si Fe Cu Mn Mg Cr Zn Ti Zr Each Total
Minimum 1.9 2 5.9 0.08
Maximum 0.12 0.5 2.5 0.1 2.7 0.04 6.9 0.06 0.15 0.05 0.15

Remainder Aluminum

7178 ALUMINUM EXTRUSIONS

CURRENTLY OFFERING TO THE FOLLOWING SPECIFICATIONS:

  • ASTM-B221

Latest Designation: AMS-QQ-A-200/13, AMS-QQ-A-200/14

Other Specifications: ABS, ASNA, LN, Werkstoff, NTA, DAN, AIR

<thcolspan=”12″>7178

7178 Others
Weight% Si Fe Cu Mn Mg Cr Zn Ti Zr Each Total
Minimum 1.6 2.4 0.18 6.3
Maximum 0.4 0.5 2.4 0.3 3.1 0.28 7.3 0.2 0.05 0.15

Remainder Aluminum
