6AL-4V TITANIUM

6AL-4V TITANIUM

Primarily used in aircraft applications where strength is required but weight is a critical factor. Ti-6Al-4V has always been the first titanium choice in the aerospace industry. Due to the fact that it is not a malleable alloy, it is more commonly used in sheet and plate applications. Regardless, there are still some tubular applications where Ti-6AL-4V is used where strength is critical.

STOCK SIZE RANGE:

OD:
1/2″ through 1-1/2″
Walls:
.020 through .028

Specifications: AMS 4911, LMA-M8003

Typical Chemical Composition %

Weight % Al V Fe O C N H Y Each Total
Minimum 5.50 3.50
Maximum 6.75 4.50 .30 .20 .08 .05 .015 .005 .10 .40

Remainder Titanium

Typical Mechanical Properties

Tensile
Ultimate/Min Yield/Min Elongation/Min
KSI KSI %
134 126 6
